Group 124R Battery Dimensions
Battery of this group has the positive post terminal located on the right. It is marked with the letter "R" because this post terminal position is called Reverse Polarity of Battery. Most batteries have it on the left side. If you want the positive post terminal to be on the left, you can turn around the 124R battery and use it as a group 124 battery, because they have identical dimensions. This will allow you to use the positive post on the left. Make sure you have enough cable length to reach the terminals, because in the turned position the terminals can be located a little further.
Battery Design |
---|
Dimensions and Sizes (Length x Width x Height) |
---|
10.375'' x 7'' x 8.625'' Inches 262 x 177 x 218 Millimeters |
Group 124R Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
Type "A" or manufacturer's custom post design |
Group 124R Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 500-700 |
Best Group 124R Batteries
List of recommended batteries
Good Choice
|
EverStart Maxx Lead Acid Automotive Battery, Group Size 124R
|
Check Price |
Group 124R Alternatives and Closest Battery Groups by Dimensions
There are no direct interchangeable alternatives for group 124R battery if we speak about dimensions, but if your battery space hasn't strict limits, you can choose a little bigger or smaller battery group. If your battery compartment cannot accommodate a larger battery, you can choose a smaller one. In both cases, you must securely fasten your new battery with a battery holder. If your battery holder can't hold the alternative battery group, you can buy a universal battery holder to fit in different types of batteries.
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 124R battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 124R group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 124R Battery | 10.375'' x 7'' x 8.625'' in. 262 x 177 x 218 mm Positive post on the Right |
12 | 6 | "A" | |
Group 24T Battery | 10.25'' x 6.8125'' x 9.75'' in. 260 x 173 x 248 mm |
12 | 6 | "A" | |
Group 28 Battery | 10.25'' x 6.8125'' x 9.4375'' in. 261 x 173 x 240 mm |
12 | 6 | "T" | |
Group 24H Battery | 10.25'' x 6.8125'' x 9.375'' in. 260 x 173 x 238 mm |
12 | 6 | "A" | |
Group 24R Battery | 10.25'' x 6.8125'' x 9'' in. 260 x 173 x 229 mm Positive post on the Right |
12 | 6 | "A", "A2" | |
Group 24 Battery | 10.25'' x 6.8125'' x 8.875'' in. 260 x 173 x 225 mm |
12 | 6 | "A", "A2" | |
Group 34R Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm Positive post on the Right |
12 | 6 | "A" | |
Group 34 Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm |
12 | 6 | "A" | |
Group 63 Battery | 10.1875'' x 6.375'' x 8.875'' in. 258 x 162 x 225 mm |
12 | 6 | "A" | |
Group 97R Battery | 9.9375'' x 6.9375'' x 7.5'' in. 252 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 47 Battery | 9.5625'' x 6.9375'' x 7.5'' in. 242 x 175 x 190 mm |
12 | 6 | "A", "A1", "F" | |
Group 90 Battery | 9.5625'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm |
12 | 6 | "A1", "A2" | |
Group 42 Battery | 9.5625'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm |
12 | 6 | "A", "A1" | |
Group 22HF Battery | 9.5'' x 6.9375'' x 9'' in. 241 x 175 x 229 mm |
12 | 6 | "A" | |
Group 22F Battery | 9.5'' x 6.9375'' x 8.3125'' in. 241 x 175 x 211 mm |
12 | 6 | "A" | |
Group 96R Battery | 9.5'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm Positive post on the Right |
12 | 6 | "A", "A1" | |
Group 67R Battery | 9.125'' x 6.9375'' x 6.9375'' in. 231 x 175 x 176 mm Positive post on the Right |
12 | 6 | "A" | |
Group 35 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
12 | 6 | "A", "A2" | |
Group 25 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
12 | 6 | "A", "A2" | |
Group 86 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
12 | 6 | "A" | |
Group 85 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
12 | 6 | "A" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 124R batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 124R Battery | 10.375'' x 7'' x 8.625'' in. 262 x 177 x 218 mm Positive post on the Right |
12 | 6 | "A" | |
Group 36R Battery | 10.375'' x 7.1875'' x 8.125'' in. 263 x 183 x 206 mm Positive post on the Right |
12 | 6 | "A" | |
Group 6T Battery | 11.25'' x 10.5'' x 9.0625'' in. 286 x 267 x 230 mm |
12 | 6 | "A" | |
Group 79 Battery | 12.0625'' x 7.0625'' x 7.375'' in. 307 x 179 x 188 mm |
12 | 6 | "S" | |
Group 77 Battery | 12.0625'' x 7.25'' x 8.75'' in. 306 x 184 x 222 mm |
12 | 6 | "A" | |
Group 65 Battery | 12.0625'' x 7.5625'' x 7.5625'' in. 306 x 192 x 192 mm |
12 | 6 | "A" |
How to Get 24 Volts from 12V of a 124R Battery Group
If you need 24 Volts, you can connect two group 124R batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 124R Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 124R batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
