Group 25 Battery Dimensions
Battery Design |
---|
![]() |
Dimensions and Sizes (Length x Width x Height) |
---|
9.0625'' x 6.9375'' x 8.875'' Inches 230 x 175 x 225 Millimeters |
Group 25 Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
![]() |
Type "A", "A2" or manufacturer's custom post design |
Group 25 Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 260-660 |
Best Group 25 Batteries
List of recommended batteries
Good Choice
![]() |
Optima Batteries 8025-160 25 RedTop Starting Battery
|
Check Price |
Good Choice
![]() |
Odyssey 25-PC1400T Automotive and LTV Battery
|
Check Price |
Best Group 25 Battery Equivalents
Compatible interchangeable batteries with the same post terminal locations.
Good Choice
![]() |
Optima Batteries OPT8022-091 8022-091 75/25 RedTop Starting Battery
|
Check Price |
Good Choice
![]() |
Optima Batteries 8042-218 D75/25 YellowTop Dual Purpose Battery
|
Check Price |
Group 25 Alternatives and Closest Battery Groups by Dimensions
Interchangeable Battery Groups for 25 Battery
These groups have the same dimensions and performance but can have different terminal post types, post locations, and polarity.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 25 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
![]() |
12 | 6 | "A", "A2" |
Group 35 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
![]() |
12 | 6 | "A", "A2" |
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 25 battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 25 group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 25 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
![]() |
12 | 6 | "A", "A2" |
Group 86 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
![]() |
12 | 6 | "A" |
Group 85 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
![]() |
12 | 6 | "A" |
Group 62 Battery | 8.875'' x 6.375'' x 8.875'' in. 225 x 162 x 225 mm |
![]() |
12 | 6 | "A" |
Group 55 Battery | 8.5625'' x 6.0625'' x 8.375'' in. 218 x 154 x 212 mm |
![]() |
12 | 6 | "A" |
Group 21R Battery | 8.1875'' x 6.8125'' x 8.75'' in. 208 x 173 x 222 mm Positive post on the Right |
![]() |
12 | 6 | "A", "A2" |
Group 21 Battery | 8.1875'' x 6.8125'' x 8.75'' in. 208 x 173 x 222 mm |
![]() |
12 | 6 | "A", "A2" |
Group 26R Battery | 8.1875'' x 6.8125'' x 7.75'' in. 208 x 173 x 197 mm Positive post on the Right |
![]() |
12 | 6 | "A" |
Group 26 Battery | 8.1875'' x 6.8125'' x 7.75'' in. 208 x 173 x 197 mm |
![]() |
12 | 6 | "A", "A2" |
Group 140R Battery | 8.125'' x 6.9375'' x 7.5'' in. 207 x 175 x 190 mm Positive post on the Right |
![]() |
12 | 6 | "A" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 25 batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 25 Battery | 9.0625'' x 6.9375'' x 8.875'' in. 230 x 175 x 225 mm |
![]() |
12 | 6 | "A", "A2" |
Group 75 Battery | 9.0625'' x 7.0625'' x 7.3125'' in. 230 x 180 x 186 mm |
![]() |
12 | 6 | "S" |
Group 72 Battery | 9.0625'' x 7.0625'' x 8.25'' in. 230 x 179 x 210 mm |
![]() |
12 | 6 | "S" |
Group 73 Battery | 9.0625'' x 7.0625'' x 8.5'' in. 230 x 179 x 216 mm |
![]() |
12 | 6 | "S" |
Group 22F Battery | 9.5'' x 6.9375'' x 8.3125'' in. 241 x 175 x 211 mm |
![]() |
12 | 6 | "A" |
Group 22HF Battery | 9.5'' x 6.9375'' x 9'' in. 241 x 175 x 229 mm |
![]() |
12 | 6 | "A" |
Group 47 Battery | 9.5625'' x 6.9375'' x 7.5'' in. 242 x 175 x 190 mm |
![]() |
12 | 6 | "A", "A1", "F" |
Group 97R Battery | 9.9375'' x 6.9375'' x 7.5'' in. 252 x 175 x 190 mm Positive post on the Right |
![]() |
12 | 6 | "A1", "A2" |
Group 59 Battery | 10.0625'' x 7.6875'' x 7.75'' in. 255 x 193 x 196 mm |
![]() |
12 | 6 | "A" |
Group 78 Battery | 10.25'' x 7.0625'' x 7.3125'' in. 260 x 180 x 186 mm |
![]() |
12 | 6 | "S" |
Group 100 Battery | 10.25'' x 7.0625'' x 7.375'' in. 260 x 179 x 188 mm |
![]() |
12 | 6 | "S" |
Group 74 Battery | 10.25'' x 7.25'' x 8.75'' in. 260 x 184 x 222 mm |
![]() |
12 | 6 | "S" |
Group 124R Battery | 10.375'' x 7'' x 8.625'' in. 262 x 177 x 218 mm Positive post on the Right |
![]() |
12 | 6 | "A" |
Group 36R Battery | 10.375'' x 7.1875'' x 8.125'' in. 263 x 183 x 206 mm Positive post on the Right |
![]() |
12 | 6 | "A" |
How to Get 24 Volts from 12V of a 25 Battery Group
If you need 24 Volts, you can connect two group 25 batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 25 Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 25 batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
