Group 76 Battery Dimensions
Battery Design |
---|
Dimensions and Sizes (Length x Width x Height) |
---|
13.125'' x 7.0625'' x 8.5'' Inches 334 x 179 x 216 Millimeters |
Group 76 Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
Type "S" or manufacturer's custom post design |
Group 76 Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 750-1075 |
Group 76 Alternatives and Closest Battery Groups by Dimensions
There are no direct interchangeable alternatives for group 76 battery if we speak about dimensions, but if your battery space hasn't strict limits, you can choose a little bigger or smaller battery group. If your battery compartment cannot accommodate a larger battery, you can choose a smaller one. In both cases, you must securely fasten your new battery with a battery holder. If your battery holder can't hold the alternative battery group, you can buy a universal battery holder to fit in different types of batteries.
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 76 battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 76 group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 76 Battery | 13.125'' x 7.0625'' x 8.5'' in. 334 x 179 x 216 mm |
12 | 6 | "S" | |
Group 43 Battery | 13.125'' x 6.9375'' x 8.0625'' in. 334 x 175 x 205 mm |
12 | 6 | "A", "A1" | |
Group 29 Battery | 13.125'' x 6.6875'' x 9.125'' in. 334 x 171 x 232 mm |
12 | 6 | "A" | |
Group 29H Battery | 13.125'' x 6.6875'' x 9.125'' in. 334 x 171 x 232 mm |
12 | 6 | "A" | |
Group 60 Battery | 13.0625'' x 6.3125'' x 8.875'' in. 332 x 160 x 225 mm |
12 | 6 | "A" | |
Group 31T Battery | 13'' x 6.8125'' x 9.4375'' in. 330 x 173 x 240 mm |
12 | 6 | "T", "M", "M1" | |
Group 31A Battery | 13'' x 6.8125'' x 9.4375'' in. 330 x 173 x 240 mm |
12 | 6 | "A", "M", "M1" | |
Group 27F Battery | 12.5'' x 6.8125'' x 8.9375'' in. 318 x 173 x 227 mm |
12 | 6 | "A", "A2" | |
Group 94R Battery | 12.4375'' x 6.9375'' x 7.5'' in. 315 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 92 Battery | 12.4375'' x 6.9375'' x 6.9375'' in. 315 x 175 x 175 mm |
12 | 6 | "A1", "A2" | |
Group 79 Battery | 12.0625'' x 7.0625'' x 7.375'' in. 307 x 179 x 188 mm |
12 | 6 | "S" | |
Group 27R Battery | 12.0625'' x 6.8125'' x 8.875'' in. 306 x 173 x 225 mm Positive post on the Right |
12 | 6 | "A", "A2" | |
Group 27 Battery | 12.0625'' x 6.8125'' x 8.875'' in. 306 x 173 x 225 mm |
12 | 6 | "A", "A2" | |
Group 27H Battery | 11.75'' x 6.8125'' x 9.25'' in. 298 x 173 x 235 mm |
12 | 6 | "A" | |
Group 64 Battery | 11.625'' x 6.375'' x 8.875'' in. 296 x 162 x 225 mm |
12 | 6 | "A" | |
Group 41 Battery | 11.5625'' x 6.9375'' x 6.9375'' in. 293 x 175 x 175 mm |
12 | 6 | "A", "A1" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 76 batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 76 Battery | 13.125'' x 7.0625'' x 8.5'' in. 334 x 179 x 216 mm |
12 | 6 | "S" | |
Group 921 Battery | 15.75'' x 7.125'' x 14.875'' in. 397 x 181 x 378 mm |
12 | 6 | "A", "L", "LPT", "HPT", "UT", "LT" | |
Group 4DLT Battery | 20'' x 8.1875'' x 7.9375'' in. 508 x 208 x 202 mm |
12 | 6 | "A" | |
Group 4D Battery | 20.75'' x 8.75'' x 9.8125'' in. 527 x 222 x 250 mm |
12 | 6 | "A", "B", "A2" | |
Group 6D Battery | 20.75'' x 10'' x 10.25'' in. 527 x 254 x 260 mm |
12 | 6 | "A", "L" |
How to Get 24 Volts from 12V of a 76 Battery Group
If you need 24 Volts, you can connect two group 76 batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 76 Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 76 batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
