Group 41 Battery Dimensions
Battery Design |
---|
Dimensions and Sizes (Length x Width x Height) |
---|
11.5625'' x 6.9375'' x 6.9375'' Inches 293 x 175 x 175 Millimeters |
Group 41 Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
Type "A", "A1" or manufacturer's custom post design |
Group 41 Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 300-720 |
Best Group 41 Batteries
List of recommended batteries
Good Choice
|
EverStart Plus Lead Acid Automotive Battery, Group 41
|
Check Price |
Group 41 Alternatives and Closest Battery Groups by Dimensions
There are no direct interchangeable alternatives for group 41 battery if we speak about dimensions, but if your battery space hasn't strict limits, you can choose a little bigger or smaller battery group. If your battery compartment cannot accommodate a larger battery, you can choose a smaller one. In both cases, you must securely fasten your new battery with a battery holder. If your battery holder can't hold the alternative battery group, you can buy a universal battery holder to fit in different types of batteries.
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 41 battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 41 group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 41 Battery | 11.5625'' x 6.9375'' x 6.9375'' in. 293 x 175 x 175 mm |
12 | 6 | "A", "A1" | |
Group 98R Battery | 11.125'' x 6.9375'' x 7.5'' in. 283 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 48 Battery | 11'' x 6.9375'' x 7.5'' in. 278 x 175 x 190 mm |
12 | 6 | "A", "A1", "A2" | |
Group 91 Battery | 11'' x 6.9375'' x 6.9375'' in. 278 x 175 x 175 mm |
12 | 6 | "A1", "A2" | |
Group 40R Battery | 11'' x 6.9375'' x 6.9375'' in. 278 x 175 x 175 mm Positive post on the Right |
12 | 6 | "A", "A1" | |
Group 124 Battery | 10.4375'' x 6.9375'' x 8.4375'' in. 265 x 175 x 214 mm |
12 | 6 | "A" | |
Group 34R Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm Positive post on the Right |
12 | 6 | "A" | |
Group 34 Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm |
12 | 6 | "A" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 41 batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 41 Battery | 11.5625'' x 6.9375'' x 6.9375'' in. 293 x 175 x 175 mm |
12 | 6 | "A", "A1" | |
Group 79 Battery | 12.0625'' x 7.0625'' x 7.375'' in. 307 x 179 x 188 mm |
12 | 6 | "S" | |
Group 65 Battery | 12.0625'' x 7.5625'' x 7.5625'' in. 306 x 192 x 192 mm |
12 | 6 | "A" | |
Group 66 Battery | 12.0625'' x 7.5625'' x 7.6875'' in. 306 x 192 x 194 mm |
12 | 6 | "A" | |
Group 92 Battery | 12.4375'' x 6.9375'' x 6.9375'' in. 315 x 175 x 175 mm |
12 | 6 | "A1", "A2" | |
Group 94R Battery | 12.4375'' x 6.9375'' x 7.5'' in. 315 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 43 Battery | 13.125'' x 6.9375'' x 8.0625'' in. 334 x 175 x 205 mm |
12 | 6 | "A", "A1" | |
Group 76 Battery | 13.125'' x 7.0625'' x 8.5'' in. 334 x 179 x 216 mm |
12 | 6 | "S" |
How to Get 24 Volts from 12V of a 41 Battery Group
If you need 24 Volts, you can connect two group 41 batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 41 Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 41 batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
