Group 24F Battery Dimensions
Battery Design |
---|
Dimensions and Sizes (Length x Width x Height) |
---|
10.75'' x 6.8125'' x 9'' Inches 273 x 173 x 229 Millimeters |
Group 24F Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
Type "A", "A2" or manufacturer's custom post design |
Group 24F Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 250-900 |
Best Group 24F Batteries
List of recommended batteries
Good Choice
|
NORTHSTAR Pure Lead Automotive Group 24F Battery NSB-AGM24F
|
Check Price |
Best Group 24F Battery Equivalents
Compatible interchangeable batteries with the same post terminal locations.
Good Choice
|
Delphi BU9034R MaxStart AGM Premium Automotive Battery, Group Size 24F / 34R
|
Check Price |
Group 24F Alternatives and Closest Battery Groups by Dimensions
Interchangeable Battery Groups for 24F Battery
These groups have the same dimensions and performance but can have different terminal post types, post locations, and polarity.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 24F Battery | 10.75'' x 6.8125'' x 9'' in. 273 x 173 x 229 mm |
12 | 6 | "A", "A2" | |
Group 46 Battery | 10.75'' x 6.8125'' x 9'' in. 273 x 173 x 229 mm |
12 | 6 | "A", "A1" |
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 24F battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 24F group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 24F Battery | 10.75'' x 6.8125'' x 9'' in. 273 x 173 x 229 mm |
12 | 6 | "A", "A2" | |
Group 24T Battery | 10.25'' x 6.8125'' x 9.75'' in. 260 x 173 x 248 mm |
12 | 6 | "A" | |
Group 28 Battery | 10.25'' x 6.8125'' x 9.4375'' in. 261 x 173 x 240 mm |
12 | 6 | "T" | |
Group 24H Battery | 10.25'' x 6.8125'' x 9.375'' in. 260 x 173 x 238 mm |
12 | 6 | "A" | |
Group 24R Battery | 10.25'' x 6.8125'' x 9'' in. 260 x 173 x 229 mm Positive post on the Right |
12 | 6 | "A", "A2" | |
Group 24 Battery | 10.25'' x 6.8125'' x 8.875'' in. 260 x 173 x 225 mm |
12 | 6 | "A", "A2" | |
Group 34R Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm Positive post on the Right |
12 | 6 | "A" | |
Group 34 Battery | 10.25'' x 6.8125'' x 7.875'' in. 260 x 173 x 200 mm |
12 | 6 | "A" | |
Group 63 Battery | 10.1875'' x 6.375'' x 8.875'' in. 258 x 162 x 225 mm |
12 | 6 | "A" | |
Group 56 Battery | 10'' x 6.0625'' x 8.375'' in. 254 x 154 x 212 mm |
12 | 6 | "A" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 24F batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 24F Battery | 10.75'' x 6.8125'' x 9'' in. 273 x 173 x 229 mm |
12 | 6 | "A", "A2" | |
Group 48 Battery | 11'' x 6.9375'' x 7.5'' in. 278 x 175 x 190 mm |
12 | 6 | "A", "A1", "A2" | |
Group 98R Battery | 11.125'' x 6.9375'' x 7.5'' in. 283 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 27H Battery | 11.75'' x 6.8125'' x 9.25'' in. 298 x 173 x 235 mm |
12 | 6 | "A" | |
Group 27 Battery | 12.0625'' x 6.8125'' x 8.875'' in. 306 x 173 x 225 mm |
12 | 6 | "A", "A2" | |
Group 27R Battery | 12.0625'' x 6.8125'' x 8.875'' in. 306 x 173 x 225 mm Positive post on the Right |
12 | 6 | "A", "A2" | |
Group 79 Battery | 12.0625'' x 7.0625'' x 7.375'' in. 307 x 179 x 188 mm |
12 | 6 | "S" | |
Group 77 Battery | 12.0625'' x 7.25'' x 8.75'' in. 306 x 184 x 222 mm |
12 | 6 | "A" | |
Group 65 Battery | 12.0625'' x 7.5625'' x 7.5625'' in. 306 x 192 x 192 mm |
12 | 6 | "A" | |
Group 66 Battery | 12.0625'' x 7.5625'' x 7.6875'' in. 306 x 192 x 194 mm |
12 | 6 | "A" |
How to Get 24 Volts from 12V of a 24F Battery Group
If you need 24 Volts, you can connect two group 24F batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 24F Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 24F batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
