Group 58 Battery Dimensions
Battery Design |
---|
Dimensions and Sizes (Length x Width x Height) |
---|
10.0625'' x 7.1875'' x 6.9375'' Inches 255 x 183 x 177 Millimeters |
Group 58 Battery Post Terminals
Post Terminal Types and Locations | Posts Used |
---|---|
Type "A" or manufacturer's custom post design |
Group 58 Battery Voltage and Current Characteristics
Volts | Cells | CCA Range |
---|---|---|
12 | 6 | 245-550 |
Best Group 58 Batteries
List of recommended batteries
Good Choice
|
EverStart Plus Lead Acid Automotive Battery, Group Size 58
|
Check Price |
Equivalents with the Reverse Polarity
Batteries in this section have identical sizes and a positive post terminal on the opposite RIGHT side.
Good Choice
|
EverStart Plus Lead Acid Automotive Battery, Group Size 58R
|
Check Price |
Group 58 Alternatives and Closest Battery Groups by Dimensions
Interchangeable Battery Groups for 58 Battery
These groups have the same dimensions and performance but can have different terminal post types, post locations, and polarity.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 58 Battery | 10.0625'' x 7.1875'' x 6.9375'' in. 255 x 183 x 177 mm |
12 | 6 | "A" | |
Group 58R Battery | 10.0625'' x 7.1875'' x 6.9375'' in. 255 x 183 x 177 mm Positive post on the Right |
12 | 6 | "A" |
Closest but not Identical Size Battery Groups
Battery groups in this section below are not identical to the group 58 battery, they can be a little bigger or smaller. Please pay attention to the post terminal types and their location
Closest Groups that Have Slightly Smaller Dimensions
Smaller batteries can have less capacity, performance, and power in comparison with 58 group.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 58 Battery | 10.0625'' x 7.1875'' x 6.9375'' in. 255 x 183 x 177 mm |
12 | 6 | "A" | |
Group 97R Battery | 9.9375'' x 6.9375'' x 7.5'' in. 252 x 175 x 190 mm Positive post on the Right |
12 | 6 | "A1", "A2" | |
Group 47 Battery | 9.5625'' x 6.9375'' x 7.5'' in. 242 x 175 x 190 mm |
12 | 6 | "A", "A1", "F" | |
Group 90 Battery | 9.5625'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm |
12 | 6 | "A1", "A2" | |
Group 42 Battery | 9.5625'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm |
12 | 6 | "A", "A1" | |
Group 22F Battery | 9.5'' x 6.9375'' x 8.3125'' in. 241 x 175 x 211 mm |
12 | 6 | "A" | |
Group 96R Battery | 9.5'' x 6.9375'' x 6.9375'' in. 242 x 175 x 175 mm Positive post on the Right |
12 | 6 | "A", "A1" | |
Group 67R Battery | 9.125'' x 6.9375'' x 6.9375'' in. 231 x 175 x 176 mm Positive post on the Right |
12 | 6 | "A" | |
Group 73 Battery | 9.0625'' x 7.0625'' x 8.5'' in. 230 x 179 x 216 mm |
12 | 6 | "S" | |
Group 72 Battery | 9.0625'' x 7.0625'' x 8.25'' in. 230 x 179 x 210 mm |
12 | 6 | "S" | |
Group 75 Battery | 9.0625'' x 7.0625'' x 7.3125'' in. 230 x 180 x 186 mm |
12 | 6 | "S" | |
Group 86 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
12 | 6 | "A" | |
Group 85 Battery | 9.0625'' x 6.8125'' x 8'' in. 230 x 173 x 203 mm |
12 | 6 | "A" |
Closest Large Dimensions
Bigger batteries can have more capacity and power compared to 58 batteries.
Battery Group Number | Dimensions | Shape | Volts | Cells | Post Terminal Type |
---|---|---|---|---|---|
Group 58 Battery | 10.0625'' x 7.1875'' x 6.9375'' in. 255 x 183 x 177 mm |
12 | 6 | "A" | |
Group 59 Battery | 10.0625'' x 7.6875'' x 7.75'' in. 255 x 193 x 196 mm |
12 | 6 | "A" | |
Group 36R Battery | 10.375'' x 7.1875'' x 8.125'' in. 263 x 183 x 206 mm Positive post on the Right |
12 | 6 | "A" | |
Group 74 Battery | 10.25'' x 7.25'' x 8.75'' in. 260 x 184 x 222 mm |
12 | 6 | "S" | |
Group 6T Battery | 11.25'' x 10.5'' x 9.0625'' in. 286 x 267 x 230 mm |
12 | 6 | "A" | |
Group 77 Battery | 12.0625'' x 7.25'' x 8.75'' in. 306 x 184 x 222 mm |
12 | 6 | "A" | |
Group 65 Battery | 12.0625'' x 7.5625'' x 7.5625'' in. 306 x 192 x 192 mm |
12 | 6 | "A" |
How to Get 24 Volts from 12V of a 58 Battery Group
If you need 24 Volts, you can connect two group 58 batteries in series to double the voltage. The voltage of a series connection is equal to the sum of the voltages of all its batteries. If one 12V lead-acid battery is connected to another 12V lead-acid battery, you have 24V total power output. Each battery must be fully charged and completely isolated from the other before connecting them in series, or there will be damage to at least one of them.
Increasing a Capacity of 58 Batteries with a Parallel Connection
If you need to increase current capacity and reduce charging time, connect batteries in parallel. When group 58 batteries are in parallel, their voltage is equal to the voltage of one battery, while current capacity equals to the sum of all its battery capacities. If you have two 12V lead-acid batteries with 60 Ah capacity and you connect them in parallel, you'll get 12 Volts with 120 Ah.
